| Einsatzbereich: |
Downhill/Gravity |
| Suspension: |
Fully |
| Radtyp: |
E-Bike |
| Laufradgröße: |
29" |
| Bremsentyp: |
Scheibenbremse |
| Rahmenmaterial: |
Carbon |
| Farbe: |
grau
|
| Federweg: |
Front: 130mm / Rear: 130mm |
| Kettenführung: |
e*thirteen / e*spec Slider |
| Kettenblatt: |
Scott custom spider / FSA 12Speed 34T chainring |
| Vorderreifen: |
Schwalbe Wicked Will 29x2.4" EVO, Super Race / TLE / 67EPI / Addix Speed Soft |
| Ladegerät: |
TQ 100-240V-4A |
| Hinterreifen: |
Schwalbe Wicked Will 29x2.4" EVO, Super Race / TLE / 67EPI / Addix Speed Grip |
| Gewicht in Kg (ca.): |
17,6 kg (Tubeless setup) |
| Max. Systemgewicht: |
128kg, Das Gesamtgewicht umfasst das Bike, den Fahrer, die Ausrüstung und eventuelles weiteres Gepäck. |
| Felgen: |
Syncros X-30SE / 32H / 30mm, Tubeless ready |
| Hinterradnabe: |
Formula CL-148M / 12x148mm / Micro Spline, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools |
| Vorderradnabe: |
Formula CL-811 / 15x110mm |
| Rahmen: |
Lumen eRIDE Carbon HMX, Integrated Suspension Technology, Flex Pivot / Adjustable head angle, Syncros Cable Integration System, TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline |
| Gabel: |
FOX 34 Float Rhythm Air Grip, 3-Modes / Kabolt 15x110mm axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 130mm travel |
| Antriebseinheit: |
TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph |
| Steuersatz: |
Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB |
| Dämpfer: |
FOX NUDE 5T EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Custom large Air volume / DPS / Reb. Adj., Travel 130-90-Lockout / T165X45mm |
| Lenker-fernbedienung: |
SCOTT TwinLoc Suspension System, 3 modes front and rear / integ. Grip clamp |
| Schaltwerk: |
Shimano XT RD-M8100 SGS, Shadow Plus / 12 Speed |
| Schalthebel: |
Shimano Deore SL-M6100-IR / Rapidfire Plus, Ispec EV clamp |
| Kurbelsatz: |
FSA Alloy crankset / 175mm / 34T |
| Bremsen: |
Shimano Deore M6120 4 Piston Disc |
| Lenker: |
Syncros Fraser 2.0 DC Alloy 6061 D.B., mini Rise / back sweep 8° / 760mm, Syncros Performance XC lock-on grips |
| Bremsscheibe: |
Front: SM-RT64 CL 180mm / Rear: RT-EM600 CL 180mm |
| Vorbau: |
Syncros DC 2.0, Syncros Cable Integration System, 0° rise / 6061 Alloy / 31.8mm / 1 1/8" |
| Sattelstütze: |
Syncros Duncan Dropper Post 2.0, 31.6mm / S & M size 125mm / L size 150mm / XL size 170mm |
| Sattel: |
Syncros Tofino 1.5 Regular, Titanium rails |
| Kette: |
Shimano CN-M6100 |
| Kassette: |
Shimano CS-M6100 / 10-51 T |
| Batterie: |
TQ Internal 360Wh |
| Display: |
TQ HPR |
| Speichen: |
Stainless Black 15G / 1.8mm |
