| Suspension: |
Fully |
| Radtyp: |
MTB-Fully |
| Laufradgröße: |
29" |
| Bremsentyp: |
Scheibenbremse |
| Rahmenmaterial: |
Carbon |
| Kettenführung: |
SCOTT custom |
| Vorderreifen: |
Maxxis Dissector / 2.6" / 60TPI Foldable, Tubeless Ready / EXO 3C maxx Terra |
| Hinterreifen: |
Maxxis Dissector / 2.6" / 60TPI Foldable, Tubeless Ready / EXO 3C maxxTerra |
| Laufradsatz: |
Syncros Revelstoke 1.5 6 Bolt, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready rim 28H / XD Driver, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools |
| Gewicht in Kg (ca.): |
14.1 (Tubeless setup) |
| Max. Systemgewicht: |
128kg |
| Gewicht in Lbs (ca.): |
31.09 (Tubeless setup) |
| Extras: |
SRAM AXS Powerpack, Syncros Fork Fender |
| Rahmen: |
Genius Carbon HMF Mainframe with Alloy 6061 Swingarm, Integrated Suspension Technology, Virtual 4 Link kinematic / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline |
| Gabel: |
FOX 36 Float Performance Elite Air FIT4, 3-Modes with low Speed adj. / Kabolt 15x110mm axle, 44mm offset / tapered steerer / Reb. Adj. / Lockout, 160mm travel |
| Steuersatz: |
Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB |
| Dämpfer: |
FOX NUDE 5T EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Custom large Air volume / DPS / Reb. Adj., Travel 150-100-Lockout / T185X55mm |
| Innenlager: |
SRAM DUB PF 92 MTB Wide / shell 41x92mm |
| Lenker-fernbedienung: |
SCOTT TwinLoc 2 Technology, Suspension & Dropper Remote, 3 Suspension modes |
| Schaltwerk: |
SRAM GX Eagle AXS Transmission 12 Speed, Wireless Electronic Shift System |
| Schalthebel: |
SRAM GX Eagle AXS Rocker Controller |
| Kurbelsatz: |
SRAM GX Eagle Transmission, DUB / 55mm CL / 32T |
| Bremsen: |
Shimano XT M8120 4 Piston Disc |
| Lenker: |
Syncros Hixon iC Carbon, Size S & M 15mm rise / Size L & XL 25mm rise, back sweep 8° / 780mm, Syncros Endurance lock-on grips |
| Bremsscheibe: |
Shimano SM-RT76 / 6 Bolt / 203/F and 180/R |
| Sattelstütze: |
Syncros Duncan Dropper Post 1.5, 31.6mm / S size 140mm / M size 160mm, L size 170mm / XL size 200mm |
| Sattel: |
Syncros Tofino 1.5 Regular, Titanium rails |
| Kette: |
SRAM CN GX Eagle Transmission |
| Kassette: |
SRAM GX Eagle XS 1275 Transmission 10-52 |
