| Gewicht in Kg (ca.): |
14.5 (with tubes / wo Pedals) |
| Max. Systemgewicht: |
128kg |
| Gewicht in Lbs (ca.): |
31.97 (with tubes / wo Pedals) |
| Felgen: |
Syncros X-20 Disc, 32H / black |
| Hinterradnabe: |
Formula DC-25 8s RQR Disc |
| Mantel: |
Kenda Booster, 2.4" / 30TPI |
| Vorderradnabe: |
Formula DC-19 FQR Disc |
| Rahmen: |
Aspect 900-700 series / Alloy 6061 Custom Tubing, BSA73 / Internal Cable Routing / replaceable hanger |
| Gabel: |
Suntour XCE28, 100mm travel |
| Steuersatz: |
Syncros OE Press Fit / 1 1/8", OD 50mm / ID 44mm |
| Innenlager: |
Feimin FP.B908N, BB73 / square taper |
| Schaltwerk: |
Shimano Tourney RD-TX800, 16 Speed |
| Umwerfer: |
Shimano FD-M315-TS / 31.8mm |
| Schalthebel: |
Shimano SL-M315, R-fire plus / 2 way release, w/gear indicator |
| Kurbelsatz: |
Prowheel TM-CY01, 36X22 w/CG |
| Bremsen: |
Clarks Clout Hydr. Disc Brakes |
| Lenker: |
HL MTB-AL-312BT / 720mm / black / 12mm rise, Syncros Pro Grip |
| Bremsscheibe: |
Clarks / 6 bolt / F&R 160mm |
| Vorbau: |
TDS-C301-8FOV / 10° / 31.8 / Black |
| Pedale: |
Feimin FP-873-ZU |
| Sattelstütze: |
HL SP C207, 31.6mm / 350mm / Black |
| Sattel: |
Syncros 3.0 |
| Kette: |
KMC Z-8.3 |
| Kassette: |
Sunrace CSM55 8AV / 11-34T |
| Speichen: |
14 G / stainless / black |
